カウンターブロー鍛造ハンマー Beche DG10H - 10 トン
仕様 (EN) - カウンターブロー鍛造ハンマー Beche DG10H - 10 トン (ID: 75452)
| Type | Counterblow forging hammer |
| Manufacturer | Beche |
| Model | DG10H |
| Energy of blow | 10`000 kg |
| Stroke | 1000 mm |
| Distance between columns | 800 mm |
| Maximum number of blow per minute | 80 |
| Average number of blow per minute | 10 |
| Air consumption per blow | 1.6 |
| Compressor output in ebm initial volume per minute | |
| with cold air operation | 16 |
| with hot air operation (160 ° C) | 10.5 |
| Power requirement of the compressor in HP at 7 atm | |
| cold air | 105 PS |
| hot air | 70 PS |
| Air collectors | 14 ebm |
| Steam consumption in kg per blow at 7 atm, strongest blow | 0.85 kg |
| Steam consumption in kg per minute | 8.5 kg |
| Height | 4500 mm |
| Weight | 50 ton |
