熱間鍛造プレス TMP Voronezh K04.038.842 - 1600 トン

Dabrox 掲載 ID: 76051

このオファーに関する詳細情報のお問い合わせ：
- 在庫状況、価格
- 支払い・配送条件
- 特性、状態、写真など

* 必須項目

仕様 (EN) - 熱間鍛造プレス TMP Voronezh K04.038.842 - 1600 トン (ID: 76051)

TypeHot forging press
ManufacturerTMP Voronezh
ModelK04.038.842
Capacity1600 ton
Slide stroke300 mm
Slide stroke length at maximum force0,16 mm
Distance adjustment between table and slider10 mm
Slide stroke number in 1 min85
Length of a rod920 mm
The closed height (the least distance between a table and a slider in his bottom position)660 mm
Table overall dimensions940 x 1200 mm
Table height above floor level450 mm
Slide overall dimensions860 x 910 mm
The size of lateral windows
— Height560 mm
— Width600 mm
Main motor90 kW
Press overall dimensions
— Length4850 mm
— Width3515 mm
— Height above floor level5570 mm
Press weight119680 kg

ビデオ - 熱間鍛造プレス TMP Voronezh K04.038.842 - 1600 トン (ID: 76051)
